Product Details



Industrial High Pressure Vacuum Air Pump Vortex Side Channel Blower Ring Regenerative Blower For Sewage Water treatment And Aeration
#High pressure air blower #Electric Air Blower #Aluminum Ring Blower # Air Pump#Fish Farming Air Blower #Vacuum Pump



MODEL Manvac  double stage side channel blower
  rated weight pakcing
size		 noise max flow vacuum pressure
Frequency power voltage   L*W*H
HZ KW V KG CM dB(A) m³/h mbar mbar
2MV 420-H46 50 2.2 200-240/345-415Y 27 48*40*43 66 150 -320 420
60 2.55 220-275 /380-480Y 69 180 -350 440
2MV 520-H46 50 3 200-240 /345-415Y 40 53*46*53 70 230 -340 410
60 3.45 220-275/380-480Y 71 275 -380 360
2MV 520-H57 50 4 345-415/600-720Y 44 72 230 -390 490
60 4.6 380-480 /660-720Y 73 275 -410 480
2MV 720-H47 50 5.5 345-415/600-720Y 66 64*52*52 66 320 -420 500
60 6.3 380-480/660-720Y 73 380 -440 440
2MV 720-H57 50 7.5 345-415/600-720Y 73 73 320 -420 610
60 8.6 380-480/660-720Y 76 380 -440 670
2MV 820-H37 50 11 345-415/600-720Y 104 72*54*54 74 520 -430 600
60 12.6  380-480/660-720Y 78 620 -460 600
2MV 820-H47 50 15.0  345-415/600-720Y 120 74 520 -460 670
60 17.3  380-480/660-720Y 78 620 -490 750
